Ignis TIG
Please choose your desired product.
Technical Data
General Data
| Welding current min. | 10 A |
|---|---|
| Welding current max. | 180 A |
| Operating voltage min. | 20,4 V |
| Open-circuit voltage | 101 V |
| Degree of protection | IP23 |
| Dimension / length | 1,43 ft |
| Dimension / width | 6,3 in |
| Dimension / height | 1,02 ft |
| Weight | 20,28 lb |
| Mains cable included | Yes |
| Earth connection | Dinse_small |
| Einschaltdauer 2 (bei 40°C) | 40 % |
| Einschaltdauer 2 (bei 40°C) | 60 % |
| Einschaltdauer 2 (bei 40°C) | 100 % |
| Schweißstrom 2 (bei 40°C) | 180 A |
| Schweißstrom 2 (bei 40°C) | 150 A |
| Schweißstrom 2 (bei 40°C) | 120 A |
| Length of mains cable | 8,2 ft |
| Maximum working voltage | 29 V |
Function overview
| Functions |
Ignis 180 XT | Ignis 180 TIG XT |
| HotStart | x | x |
| SoftStart | x | x |
| Anti-stick | x | x |
| MMA Pulse | x | x |
| TAC tacking function | x | |
| TIG Comfort Stop | x | x |
| TIG Pulse | x | |
| TIG Multi Connector | x | |
| TIG welding torch operation | x | |
| Remote control operation | x | |
| Time shutdown (300 s/900 s/off) |
x | x |
| TrackingArc | x | x |
| XT variant | x | x |
